60V
POWER BATTERIES / LiFePO4 TWO-WHEELER / DM60110
60V
100Ah
This page separates the selected configuration from the family range, so buyers can verify the enclosure, electrical window and included charger before submitting one combined quotation request.
6.4 kWhIP65Electric three-wheeler
01 / DM60110
Verified product specifications
A battery is compatible only when voltage window, dimensions, connector, polarity, discharge current, controller, charger and communication interface all match the vehicle. Final electrical interfaces must be confirmed before production.
REQUEST MATCHING CHECK ↗- Nominal voltage
- 64 V
- Voltage range
- 50–73 V
- Capacity
- 100 Ah
- Nominal energy
- 6.4 kWh
- Dimensions
- 539 × 294 × 199 mm
- Net weight
- 52.1 ± 0.5 kg
- Ingress protection
- IP65
- Cell chemistry
- LiFePO4
- Series cells
- 20
- Operating temperature
- −30 to 55 °C
- Included charger
- 15A charger
- Application
- Electric three-wheeler
02 / SOURCE MATERIAL
Product information gallery
Technical values are transcribed from the supplied SKU sheets. GB/T 36672-2018 is shown on those source sheets. Final export conformity, connector, BMS current and warranty terms must be confirmed in the signed datasheet and PI.
